易语言UDP工作线程源码

系统结构:回调函数,启动,停止,错误,发送数据,工作线程,超时重发机制,启动IOCP,销毁IOCP,GetInt,mAlloc,mFree,PostWSARecv,PostWSASend,Release,Release2,WriteReturn,GetReturn,GetType,GetBuff,GetFrom,WriteType,WriteBuff,WriteFrom,创建Overlapped,WriteBuffHeader,GetBuffHeader,ReadByte,WriteHeader,WriteSys,WriteByte,WriteSint,WriteInt,ReadInt,ReadChar,PostSendOv,调用原函数,汇编_CALL,创建,WSARecvFrom,WSASendTo,WSASendTo_套接字,lstrcpyn_sockaddr,

======窗口程序集1
           |  |
           |  |------ __启动窗口_创建完毕
           |  |
           |  |------ __启动窗口_可否被关闭
           |  |
           |  |------ 回调函数
           |  |
           |  |------ _按钮1_被单击
           |  |
           |  |------ _时钟1_周期事件
           |  |
           |  |------ _按钮2_被单击
           |  |
           |  |------ _按钮3_被单击
           |  |
           |  |
======UDP
           |  |
           |  |------ _初始化
           |  |
           |  |------ _销毁
           |  |
           |  |------ 启动
           |  |
           |  |------ 停止
           |  |
           |  |------ 错误
           |  |
           |  |------ 发送数据
           |  |
           |  |
======线程处理
           |  |
           |  |------ 工作线程
           |  |
           |  |------ 超时重发机制
           |  |
           |  |------ 启动IOCP
           |  |
           |  |------ 销毁IOCP
           |  |
           |  |
======内存处理
           |  |
           |  |------ GetInt
           |  |
           |  |------ mAlloc
           |  |
           |  |------ mFree
           |  |
           |  |------ PostWSARecv
           |  |
           |  |------ PostWSASend
           |  |
           |  |------ Release
           |  |
           |  |------ Release2
           |  |
           |  |
======辅助程序
           |  |
           |  |------ WriteReturn
           |  |
           |  |------ GetReturn
           |  |
           |  |------ GetType
           |  |
           |  |------ GetBuff
           |  |
           |  |------ GetFrom
           |  |
           |  |------ WriteType
           |  |
           |  |------ WriteBuff
           |  |
           |  |------ WriteFrom
           |  |
           |  |------ 创建Overlapped
           |  |
           |  |------ WriteBuffHeader
           |  |
           |  |------ GetBuffHeader
           |  |
           |  |------ ReadByte
           |  |
           |  |------ WriteHeader
           |  |
           |  |------ WriteSys
           |  |
           |  |------ WriteByte
           |  |
           |  |------ WriteSint
           |  |
           |  |------ WriteInt
           |  |
           |  |------ ReadInt
           |  |
           |  |------ ReadChar
           |  |
           |  |------ PostSendOv
           |  |
           |  |------ 调用原函数
           |  |
           |  |------ _取子程序地址
           |  |
           |  |------ _取字节集数据地址
           |  |
           |  |------ _取文本数据地址
           |  |
           |  |------ _取整数型数据地址
           |  |
           |  |------ 汇编_CALL
           |  |
           |  |
======分包处理类
           |  |
           |  |------ _初始化
           |  |
           |  |------ _销毁
           |  |
           |  |------ 创建
           |  |
           |  |
======调用的Dll
           |  |
           |  |---[dll]------   WSARecvFrom
           |  |
           |  |---[dll]------   WSASendTo
           |  |
           |  |---[dll]------   WSASendTo_套接字
           |  |
           |  |---[dll]------   lstrcpyn_sockaddr

调用的DLL命令:

.DLL命令 WSARecvFrom, 整数型, "ws2_32.dll", "WSARecvFrom"
    .参数 s, 整数型
    .参数 lpBuffers, 整数型
    .参数 dwBufferCount, 整数型
    .参数 lpNumberOfBytesRecvd, 整数型, 传址
    .参数 iFlags, 整数型, 传址
    .参数 lpFrom, 整数型, , 接收人地址
    .参数 lpFromlen, 整数型, 传址, 长度 16
    .参数 lpOverlapped, 整数型
    .参数 lpCompletionRoutine, 整数型, , 0

.DLL命令 WSASendTo, 整数型, "ws2_32.dll", "WSASendTo"
    .参数 s, 整数型
    .参数 lpBuffers, 整数型
    .参数 dwBufferCount, 整数型
    .参数 lpNumberOfBytesSent, 整数型, 传址
    .参数 iFlags, 整数型
    .参数 lpTo, 整数型
    .参数 iToLen, 整数型, 传址, 16
    .参数 lpOverlapped, 整数型
    .参数 lpCompletionRoutine, 整数型, , 0

.DLL命令 WSASendTo_套接字, 整数型, "ws2_32.dll", "WSASendTo"
    .参数 s, 整数型
    .参数 lpBuffers, 整数型
    .参数 dwBufferCount, 整数型
    .参数 lpNumberOfBytesSent, 整数型, 传址
    .参数 iFlags, 整数型
    .参数 lpTo, sockaddr, 传址
    .参数 iToLen, 整数型, 传址, 16
    .参数 lpOverlapped, 整数型
    .参数 lpCompletionRoutine, 整数型, , 0

.DLL命令 lstrcpyn_sockaddr, 整数型, "kernel32.dll", "lstrcpynA"
    .参数 短整数, sockaddr, 传址
    .参数 短整数, sockaddr, 传址
    .参数 iFang, 整数型
